| Utilização | Características | Especificações |
| | 1. Support up to 16ch IPCAM simultaneously | Type | VDH-620NV (16CH HD720p ) |
| | 2. Built-in DDNS domain name | SOC | Hi3520 |
| | 3. No port forwarding necessary | Video Input | Support IP CAM x 16PCS |
| | 4. Free CMS supporting Mac OS and Windows | Video Output | CVBS (BNC) / VGA / Digital Output |
| | 5. Support major mobile phone OS | Audio Input / Output | 1ch Input / 1ch Output |
| | 6. Stable, easy-to-maintain, and scalable system | Display Resolution | 720P (1280x720) |
| | | Alarm Input / Output | 4CH Alarm In / 1 CH Alarm Out |
| | | Compression Algorithm | H.264 |
| | | Video Format | NTSC / PAL |
| | | Display Resolution | VGA (800X600 / 1280X1024 ) |
| | | Digital Output (1920 x 1080) |
| | | YPbPr Output(1920 x 1080) |
| | | Performances | 400 / 480fps 720P record, and 4CH 720P playback |
| | | Record Resolution | CIF/720P |
| | | Motion Detection | Video Motion |
| | | Record Mode | Time/Sensor/Motion |
| | | HDD | SATA 3.5”HDD (Max 2TB) x 4 pcs (No HDD Included) |
| | | P/T/Z Control | RS-485 |
| | | Network Resolution | CIF / 720P |
| | | Network Protocol | DHCP,DDNS,UPNP,SMTP,FAB |
| | | Browser | Internet Explorer (Windows) |
| | | CMS | WINDOWS / iMac |
| | | 3G Mobile OS | Windows Mobile, iPhone, Android, Symbian, Blackberry |
| | | Control Mode | Remote Control / USB Mouse / Internet |
| | | USB | USB x 2PCS |
| | | Power | ATX 150W AC 115V~230V |
| | | Dimensions | 419mm (W) x 392.6mm (D) x97mm (H) |
| | | Net Weight | 4.5kg (HDD Not Included) |
